Cut without LPG / D.A. & Oxygen with Air Plasma
Cut without LPG / D.A. & Oxygen with Air Plasma
Cut without LPG / D.A. & Oxygen with Air Plasma
We bring forth a wide range of welding machines those are used in various industries. Cut without LPG / D.A. & Oxygen with Air Plasma offered by us has been designed as per the international standards therefore it is widely accepted on global scale. This is equipped with standard tools capable of offering required performance. We let our products to go through a quality test ensuring their flawlessness. With following specifications Cut without LPG / D.A. & Oxygen with Air Plasma machines are available.
Technical Specification
| S.no. |
Model |
KPT-6 |
KPT-10 |
KPT-16 |
KPT-30 |
KPT-40 |
KPT-50 |
| 1 |
Supply Voltage |
380-440 V |
380-440 V |
380-440 V |
380-440 V |
380-440 V |
380-440 V |
| 2 |
Phase |
3 |
3 |
3 |
3 |
3 |
3 |
| 3 |
Frequency |
50 Hz |
50 Hz |
50 Hz |
50 Hz |
50 Hz |
50 Hz |
| 4 |
O.C.V( No Load) |
300-320 VDC |
300-320 VDC |
300-320 VDC |
300-320 VDC |
300-320 VDC |
300-320 VDC |
| 5 |
Insulation Class |
F |
F |
F |
F |
F |
F |
| 6 |
Duty Cycle |
100% |
100% |
100% |
100% |
100% |
100% |
| 7 |
Recommended Air Pressure |
6 Kg/cm2 |
6 Kg/cm2 |
6 Kg/cm2 |
6 Kg/cm2 |
6 Kg/cm2 |
6 Kg/cm2 |
| 8 |
Cutting Capacity for
SS Clean Cut
for SS Parting Cut |
6 mm
10 mm |
10 mm
15 mm |
16 mm
20 mm |
30 mm
35 mm |
40 mm
45 mm |
50 mm
60 mm |
